250CC ATV(ATV250-9A)


Back


1.Engine:single-cylinder; four-stroke;air cooled engine
2.Displacement:250cc
3.Starting mode:electric start
4.Ignition:CDI
5.Maximum output and rotating speed:12.5kw/7500r/min??5%
6.Maximum torque and rotating speed:17.6n.m/7500r/min??5%
7.Rated power and rotating speed:10.5kw??/7000r/min??5%
8.Bore and stroke :67/64.8mm
9.Compression Ratio :9.2:1
10.Tire size:front 21*17-10,rear 20*10-10
11.Wheel base:1130mm
12.Seat height:810mm
13.Mininum ground clearance:150mm
14.Fuel tank capacity:5.5L
15.Water machine capacity:2.6L
16.Max speed:75km/h
17.Loading:150kgs
18.Net /gress weight :167/184kgs Bike size:1810X1150X1160MM
19.Carton size:1500X940X870MM
20.Container:20FT:14psc 40FT:32PCS 40HQ:48pcs




If you have any question,please send email to sales@upbeatmoto.com
